RS PRO Multi timer RS PRO SPDT 280 → 520V ac 17.5mm
#Grup produk P115233177
Sebelum PPN:
Rp1.999.900 - Rp2.399.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
|---|
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
SpecificationMonitoring application: phase, voltage, power supply voltage: 280 -> 520 V ac, contact configuration: SPDT, voltage sensitivity: undervoltage, electrical phase: 3, voltage detection range: maximum 280 V, phase sensitivity: phase fault, phase sequence, delay Time: 100 ms, Frequency detection range: 48 -> 63 Hz, Operating temperature range: -20 -> +60 °C, UL certified. LX series-Three phase relay. L series relay products timer, control, three phase relay are the latest It is equipped with technology and has a wide range of functions that the user can select. .17.5 mm DIN rail housing Microprocessor base Measures phase-to-phase voltage SPDT relay output 8 A x 1 Green LED display for power status Red LED display for relay status
