Installation compatible with the B3F series, and high reliability achieved by the seal structure.
Seal structure equivalent to IP67 (IEC-60529) ensures high contact reliability even when used in dusty locations or around water. (Excluding the terminal section.)
Available in two types: small and thin, 6mm square and 12mm square. A series with a ground terminal that is convenient for static electricity countermeasures is also available.
A convex plunger is available to which a key top (B32 series) can be attached.
OMRON Seal Type Tactile Switch B3W
#Grup produk P115119248
Spesifikasi
| Color | (Plunger) Yellow |
|---|---|
| Contact Configuration | 1a (normally open contact) |
| Electrical Rating | DC3 ~ 24V + 1 ~ 50mA + Resistive load |
| Height (mm) | 7.3 |
| Insulation Resistance (MΩ) | 100 or more (at 250 VDC mega) |
| Operating Humidity Range | 35~85% RH (at +5~+ 35 ° C) |
| Operating Temperature Range (°C) | -25~+70 60% RH or less (no freezing or condensation) |
| Shock Resistance (m/s²) | Up to 1000 |
| Shock Resistance Malfunction (m/s²) | Up to 100 |
| Vibration Resistance (Malfunction) | 10-50Hz, double amplitude 1.5mm |
| Withstand Voltage | AC500V 50/60Hz 1min |
