Sumitomo Electric Hard Metal Chip TBGT-FY
#Grup produk P114329015
Spesifikasi
| Blade Length l (mm) | 6.9 |
|---|---|
| Chip breaker | One side |
| Clearance Angle (°) | 5 |
| Corner Height Tolerance (mm) | ±0.025 |
| Cutting Blade Length (mm) | 6.9 |
| Material | AC530U |
| Nose Radius r (mm) | 0.1 |
| Right or Left Hand | Left |
| Shape | Equilateral triangle 60 ° |
| Socket Shape | Partially cylindrical hole one side 40 ° -60 ° |
| Thickness (mm) | 1.59 |
| Thickness Tolerance (mm) | ±0.13 |
| Thickness s (mm) | 1.59 |
| Tolerance of Inscribed Circle (mm) | ±0.025 |
| Type | Positive |
| With Or Without Hole | Yes |
