This pressure gauge has a structure that transmits the elastic deformation (movement) of the Bourdon tube to the pointer, and is easy to handle due to its simple structure. It can also measure a wide range of pressures, and is used in a wide range of fields.
The use of a sealed case allows it to be used even under rain and dew conditions (equivalent to JIS C 0920 IP43).
NAGANO KEIKI Sealed pressure gauge (150Φ) 5MPa Vertical B frame BG12-231 series
#Grup produk P113800896
Spesifikasi
| AS ONE Part Number | 65-4305-94 |
|---|
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Specification*Size (mm): DIA150 *Shape (mounting): Vertical B frame *Connection: G3/8B *Material: Brass *Performance: None *Pressure range: MPa_0~5 *Accuracy: ±1.5%FS *Processing: None *Classification: 0
