It is a high-end model "S line series" that pursues high functionality and high performance. Built-in wired transmission function. To guarantee accuracy, it comes with an inspection table that shows the values at the time of inspection. It has a reference function that remembers the zero point even when the power is turned off. The liquid crystal part rotates 270 ° and can be installed in an easy-to-see direction. With tolerance setting function. With a function to switch the measurement direction (+-). Comes with a preset function. With auto-off function (0-999 minutes).
For measuring displacement such as unevenness of a flat surface, good / bad mounting of a workpiece, runout of a shaft, and squareness.
* The instruction error for the entire measurement range does not include the quantization error (± 1 count). * A transfer cable (sold separately) is required to send data. * Operating temperature range (°C): 10-40 * Data transmission connection unit: DTC-M1 (wired)
SK (Niigata Seiki) Digital S-Line Indicator
#Grup produk P113732188
Spesifikasi
| AS ONE Part Number | 65-2724-74 |
|---|---|
| Power Supply | CR2450 (included for testing) |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Type | Standard |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Warning
* The instruction error for the entire measurement range does not include the quantization error (± 1 count). * A transfer cable (sold separately) is required to send data. * Operating temperature range (°C): 10-40 * Data transmission connection unit: DTC-M1 (wired)Feature
It is a high-end model "S line series" that pursues high functionality and high performance. Built-in wired transmission function. To guarantee accuracy, it comes with an inspection table that shows the values at the time of inspection. It has a reference function that remembers the zero point even when the power is turned off. The liquid crystal part rotates 270 ° and can be installed in an easy-to-see direction. With tolerance setting function. With a function to switch the measurement direction (+-). Comes with a preset function. With auto-off function (0-999 minutes).* Measurement range (mm): 12.5 * Minimum reading (mm): 0.0001 * Minimum display value (mm): 0.01 / 0.005 / 0.002 / 0.001 / 0.0005 / 0.0001 * Return error (μm): 0.6 * Measuring force (N) : 1.5 or less * Indication error for the entire measurement range (μm): 1.8 * Repeat accuracy (μm): 0.5
Use
For measuring displacement such as unevenness of a flat surface, good / bad mounting of a workpiece, runout of a shaft, and squareness.Ulasan Produk
