The cable is 50cm long, so you can easily route even short display cables.
It comes with a hook-and-loop fastener so that it can be fixed to a desk or other surface, preventing the unit from floating due to the cable's bounce.
Equipped with a Type-C connector, it can be used with computers and other devices equipped with a Type-C port.
It has a built-in adapter that converts the USB Type-C port into a LAN port.
It converts USB to a LAN port, making it ideal for connecting to a LAN via a wired connection.
Supports Gigabit LAN.
It supports "DisplayPort Alternate Mode," which allows you to add an HDMI display via USB Type-C connection, so you can easily create a multi-display environment (mirror mode/extended mode) without installing any software.
Supports USB 5Gbps (USB3.2/3.1/3.0) SuperSpeed Mode (5Gbps) (theoretical value).
The Type-C port supports both PD and data transfer.
It supports USB Power Delivery (USB PD) via USB Type-C, so you can also power a connected computer via this product.
*The computer must be PD compatible.
*A separate PD adapter is required.
*Models that have a USB port (Type-C female) and whose operation is guaranteed by the computer manufacturer.
*To operate in a USB 5Gbps environment, the computer itself must have a USB 5Gbps port.
*Some computers and USB devices may not be compatible.
*Only compatible with PCs with Type-C ports that support each video output (DisplayPort Alt Mode).
*Operation is not guaranteed on all devices.
*Cables, TVs, and displays that support each resolution are required.
*Not compatible with displays with USB Type-C connection.
SANWA SUPPLY Docking Station_USB 5Gbps
#Grup produk P113479465
Spesifikasi
| Set Contents | Hook-and-loop fastener |
|---|
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Specification[PC Connection Terminal] ■ Connector Shape: USB Type-C ■ Compatible Standards: USB 5Gbps (USB3.2 Gen1/3.1 Gen1/3.0) compliant. *USB 5Gbps is the same standard as USB3.2 Gen1 (USB3.1 Gen1/USB3.0), renamed by the USB-IF (USB Implementers Forum). ■ Maximum USB PD Output: 88W ■ Cable Length: Approximately 50cm ■ Cable Type: Integrated Cable [USB Ports] ■ Number of Ports: 3 ■ Maximum Data Transfer Speed (Theoretical): 5Gbps ■ USB Type-C Female / USB 5Gbps: 1 PD-compatible port (PD & data compatible) * Not compatible with USB Type-C monitors. ■ USB A Female / USB 5Gbps: 2 ports ■ Supply Current: Maximum 3000mA (Total of all ports: Bus-powered)
*If the connected device's current consumption exceeds the current supplied by this product, it may not function properly with bus power. [Power Supply] ■ Power Supply Method: Bus Powered/Self-Powered (when connected to a power source) ■ Unit Power Consumption: 8W ■ USB PD Input Port: Yes ■ Maximum USB PD Input: 100W *Depending on your computer and PD power adapter, you may see a warning recommending using the power adapter included with your computer, but this does not affect operation. [Video Output Port] ■ Number of Supported Output Displays: 1 ■ Maximum Supported Resolution: 4K/30Hz *The supported resolutions listed require your computer to support DisplayPort Alt Mode (DP1.4 or higher).
*4K resolution output requires a 4K-compatible display and the output content must also support 4K resolution. ■Maximum supported resolution/refresh rate: 3840 x 2160 ■HDCP: 2.3, 2.2, 2, 1.4 ■HDMI: 1 port ■VGA: 1 port [LAN port] ■Port type: RJ-45 port (Auto MDI/MDI-X), Auto-Negotiation supported *Wake-on-LAN functionality is supported, but support varies depending on the computer model, so operation is not guaranteed.
*Depending on the connected device, Wi-Fi may need to be turned off to use a wired network. ■Compatible standards: IEEE802.3 (10BASE-T), IEEE802.3u (100BASE-TX), IEEE802.3ab (1000BASE-T) ■Transmission speed (theoretical value): 1000Mbps, 100Mbps, 10Mbps *Regarding communication speed, 1000BASE-T is supported only when connected to USB 5Gbps (USB 3.2 Gen 1). ■Access method: CSMA/CD [Common specifications] ■Supported OS Windows: 11, 10 ■Supported OS mac: macOS (Sequoia) 15, macOS (Sonoma) 14, macOS (Ventura) 13, macOS (Monterey) 12, macOS (Big Sur) 11 ■Supported OS iPadOS: iPadOS 17, 18 ■Supported OS ChromeOS: ChromeOS ■Supported models: Windows (DOS/V) PCs, Apple Mac series, ChromeOS PCs *Models that have a USB port (Type-C female) and whose USB port operation is guaranteed by the PC manufacturer.
*In order to operate in a USB 5 Gbps (USB 3.2 Gen 1) environment, the computer itself must have a USB 5 Gbps (USB 3.2 Gen 1) port.
*Not compatible with monitors with USB Type-C connection.
*Only Type-C ports that support video output (DisplayPort Alt Mode) are supported.
*Some computers and USB devices may not be compatible.
