- Achieves compact and efficient power transmission in unequal shaft power transmission, which has traditionally been achieved with spline shafts and the like.
- NSS models are capable of not only simple unequal shaft power transmission, but also a wide range of parallel movement of the center of rotation.
- Schmidt couplings are unequal shaft joints that utilize the crank motion of the links.
- Power input to one end disc is transmitted to the other end disc via the links and center disc.
- Except for slight friction loss in the bearings, both rotational speed and torque are reliably transmitted from the drive side.
Miki pulley Schmidt coupling NSS20.9.20/4
#Grup produk P112600545
Spesifikasi
| Dimension B (mm) | 196 |
|---|---|
| Dimension D (mm) | 200 |
| Dimension K (mm) | 30 |
| Dimension M | M20 |
| Dimension N (mm) | 4 |
| Dimension S (mm) | 90 |
| Dimension Z (mm) | 150 |
| Eccentricity (mm) | [Min. S x 0.25] 23 [Max. S x 0.95] 85 [Straight line maximum] 165 |
| Number of links | 4x2 |
