- Achieves compact and efficient power transmission in unequal shaft power transmission, which has traditionally been achieved with spline shafts and the like.
- NSS models are capable of not only simple unequal shaft power transmission, but also a wide range of parallel movement of the center of rotation.
- Schmidt couplings are unequal shaft joints that utilize the crank motion of the links.
- Power input to one end disc is transmitted to the other end disc via the links and center disc.
- Except for slight friction loss in the bearings, both rotational speed and torque are reliably transmitted from the drive side.
Miki pulley Schmidt coupling NSS16.10.16
#Grup produk P112600509
Spesifikasi
| Dimension B (mm) | 155 |
|---|---|
| Dimension D (mm) | 160 |
| Dimension K (mm) | 25 |
| Dimension M | M16 |
| Dimension N (mm) | 3 |
| Dimension S (mm) | 100 |
| Dimension Z (mm) | 115 |
| Eccentricity (mm) | [Min. S x 0.25] 25 [Max. S x 0.95] 95 [Straight line maximum] 183 |
| Number of links | 3x2 |
