Fuji Electric Power module
#Grup produk P112576585
Spesifikasi
| Allowable Ripple | Three-phase full-wave rectified waveform 5% or less |
|---|---|
| Allowable Voltage Range (V) | DC19.2 to 30 |
| Dielectric Strength | AC510V 1 minute between power input terminal batch and ground |
| Feature | By enabling power supply from multiple power supply modules, power supply redundancy has been achieved. (Up to 3). System reliability can be improved by making the power supply redundant. |
| Inrush Current (A) | 150Ao-p or less 2ms or less |
| Insulation Resistance (MΩ) | DC500V insulation resistance tester 10 or more |
| Leakage Current (mA) | 0.25 or less |
| Mass (g) | About 360 |
| Number of Occupied Slots | 2 slots |
| Output Current (A) | 0 to 1.46 |
| Power Consumption (W) | 45 or less |
| Rated Input Voltage (V) | DC24 |
| Rated Output Voltage (V) | DC24(DC22.8 to 26.4) |
| Suitable Model | MICREX-SX series SPH |
| Type of Insulation | Isolation by transformer |
