High Power Relays
APPROVALS : UL (File no. E134517), CQC (File no. CQC0200100195Heavy load up to 5000VA, ideal for motor switching
Withstands inrush current of 80A
Fitted with 6.3mm quick connect male terminals
4.5kV dielectric strength (between coil and contacts)
Flux proof construction
RS PRO Coil Non-Latching Relay
#Grup produk P112205669
Spesifikasi
| Coil Power (mW) | 900 |
|---|---|
| Coil Resistance (ohm) | 160 |
| Coil Voltage (V) | 12 DC |
| Contact Configuration | SPNO |
| Depth (mm) | 16 |
| Height (mm) | 33.5 |
| Isolation Coil to Contact (kV) | 4.5 ac |
| Length (mm) | 30.5 |
| Maximum Switching Power AC (kVA) | 6.25 |
| Maximum Switching Voltage AC (V) | 250AC |
| Mounting Type | PCB Mount |
| Number of Poles | 1 |
| Standards Met | CQC, CULus, RoHS Compliant |
| Switching Current (A) | 25 |
| Terminal Type | Through Hole |
