Yoshitake Solenoid Valve / REDMAN DP-200F
#Grup produk P111936133
Sebelum PPN:
Rp10.999.900 - Rp16.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Ambient Temperature (°C) | 50 or less (no freezing) |
|---|---|
| Connector | JIS 10KFF flange |
| Kinds | Solenoid Valve |
| Material (Valve Box) | SCS |
| Material (Valve Member) | NBR (diaphragm) |
| Maximum Operating Pressure (MPa) | 0 to 1.0 (vacuum cannot be used) |
| Minimum Operating Pressure (MPa) | 0 (Differential pressure of 0.1 or more is required for horizontal coils) |
| Mounting Direction | Horizontal / vertical freedom (up to 90 ° to coil upward) |
| Operating Pressure Range (MPa) | 0 to 1.0 (vacuum cannot be used) |
| Operating Temperature (°C) | 5 to 60 |
| Operating Temperature Range (°C) | 5 to 60 |
| Suitable fluid | Cold / hot water, air, nitrogen gas, argon gas, oil (20 cSt or less) |
| Type | Pilot type diaphragm |
| Valve Seat Leakage | None (confirmed visually by pressure gauge) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Open type diamond flap type when energized. The impact of the water hammer is reduced and the valve closing time is shortened. Since the valve part uses synthetic rubber, there is no leakage of the valve seat. The mounting posture is horizontal and vertical (however, within 90 ° with respect to the coil upward).
