Further speeding up and moving to the motion controller area with a synchronous system.
2-axis, 4-axis unit, open collector output type / line driver output type are available.
2-axis and 4-axis control. In addition to servo motors and pulse motors, linear motors and DD motors support high-speed and high-resolution positioning.
OMRON SYSMAC CJ Series Position Control Unit (High Speed Type)
#Grup produk P106931994
Sebelum PPN:
Rp32.999.900 - Rp42.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Speed Command | Data: Position control/1 to 2147483647, Speed control/-2147483648 to 2147483647 (however, the upper limit of output frequency is limited by the maximum speed) Number of data: 500/task |
|---|---|
| Allowable Voltage Range (V) | 21.6 to 26.4 DC (external power supply) |
| Applicable Standard | cULus (ClassⅠDiv2 hazardous area certified product) |
| Pulse Output | Phase difference pulse output, positive / negative direction pulse output, pulse + direction output |
| Control Unit | Pulse, mm, inch, degree |
| Type | Built-in pulse counter function |
| Function | Positioning (memory operation, direct operation), override (0.01-500.00%, settable for each axis), software limit (-2147483647 to 2147483646 command units, settable for each axis), backlash correction (0 to 50000 command units, (Can be set for each axis) |
| Input Channel | MPG/external encoder counter input/1CH (switchable for each control axis) Feedback pulse counter input/4CH (1CH/axis) |
| Interface | MPG/external encoder counter input/photocoupler input Feedback pulse counter input/line receiver input |
| Number of Connections | Maximum number of units that can be installed per device / 5 units Maximum number of units that can be installed per CJ system / 20 units (when connecting up to 3 expansion units) |
| Occupied In/Out Points | 18CH |
| Operating Ambient Temperature (°C) | 0 to 55 |
| Power Supply Voltage (V) | DC5 (Unit body) / DC24 (External power supply) |
| Suitable For | (PLC) CJ series |
| Type of control | Open loop control by pulse train output |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Warning
This unit cannot be used with the Machine Automation Controller NJ series. The I / O occupied point is the number of occupied channels of the high function I / O unit relay. Other than this, it occupies an area of up to 144 channels depending on the number of axes and functions used.
