OMRON Programmable Controller CJ1/CJ1M Loop CPU Unit
#Grup produk P106916384
Sebelum PPN:
Rp36.999.900 - Rp63.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Suitable For | tool software/ (CPU part) CX-Programmer, CX-Simulator, etc. (Loop control part) CX-Processtool |
|---|---|
| Method | (Calculation) Instrument block method |
| Current Consumption (A) | 1.06 (5V system) (including current consumption of the process controller) |
| Type of control | Combinable control/basic PID control, cascade control, feedforward control, sample PI control, Smith dead time compensation control, gap PID, override control, program control, time proportional control, etc. |
| Alarm Function | PID block built-in/1PID block, PV alarm 4 points (upper limit, upper limit, lower limit, lower limit limit), deviation alarm 1 pointAlarm block/upper and lower limit alarm block, deviation alarm block |
| Applicable Standard | cULus (Class I Div 2 hazardous area certified product), EC Directive |
| Back-up Time (minute) | Super capacitor: 25°C for 5 |
| Control Calculation Cycle (s) | (Instrument block) Setable Cycle / 0.01, 0.02, 0.05, 0.1, 0.2, 0.5, 1, 2s (Default/1); Settings can also be set for each unit block. (0.01 to 0.05s can not be set in some blocks) |
| Data Retention | Backup with super capacitor, data stored in flash memory, backup from RAM to flash memory, recovery from flash memory to RAM |
| Loop Control Section | Setting unit: None, Display unit: 2 LEDs (in operation, ready) |
| Processing Speed (ms/command) | (LD) 0.04 |
| Response Time | In the external I/O/1 control loop, the time from the input of an analog signal to the output of the analog signal to the outside depends on the calculation cycle of the instrument block and the cycle time of the CPU unit. |
| Time (ms) | Impact time on the cycle time of the CPU unit/Max. 0.8 (depends on the data contents of the instrument block) |
