Up to 8 digital I / O, analog I / O, and relay output units compatible with multiple I / O terminals can be connected.
Flexible combination of I / O points is possible.
The total extension is 3m.
DIN rail mounting.
OMRON Devicenet Communication Unit
#Grup produk P106895276
Spesifikasi
| Storage Temperature (°C) | -25 to +65 (with no icing or condensation) |
|---|---|
| Vibration Resistance | 10 to 150Hz, double amplitude 1.0mm or 70m / s <sup>2</sup> |
| Included Accessories | End connector x 1 |
| Type of Terminal Fitting | DIN 35mm rail mounting |
| Ambient Relative Humidity (RH) | 25 to 85 |
| Communication Distance (m) | Total extension: Max. 3 Between units: Max. 1 (However, the standard accessory cable is 40mm) |
| Communication Power Supply Voltage (V) | DC11-25 (supplied from communication connector) |
| Current Consumption | Communication power supply: 30 mA or less Internal power supply: 24 VDC 0.6 A or less (at I/O unit maximum load) |
| I / O Power Supply Voltage (V) | DC20.4 to 26.4(DC24V -15 to +10%) |
| Mounting Strength (N) | 100 in each direction (however, rail direction is 10N or more) |
| Noise resistance | Compliant with IEC61000-4-4, 2kV (power line) |
| Number of Connections | Unit / 8 units |
| Number of Input/Output Points | (Unit) Maximum IN, OUT total 1,024 points |
| Operating Ambient Temperature (°C) | -10 to +55 (with no icing or condensation) |
| Output Current (A) | Unit power supply / max.0.4 (The total current consumption of I / O unit interface should be 0.4A or less) |
| Power Supply Voltage (V) | DC24 |
| Screw Tightening Torque (N・M) | 0.3-0.5 (Phoenix connector: 0.25-0.3) |
| Shock Resistance (m/s2) | 200 |
| Terminal Strength (N) | Tensile strength 100 |
| Withstand Voltage (V) | AC500 |
