CKD Simple Flood Control FK / Female Thread Type

Deviation core during cylinder mounting, simplified Flocon to easily solve the parallelism Dimension F (mm)=2 ^{+0.1 ; Dimension K (mm)=3 _{-0.1 ; Dimension O (mm)=24; Dimension B (mm)=10; Dimension P (mm)=34; Dimension R (mm)=8; Dimension E (mm)=3.1; Dimension M (mm)=14; Dimension D (mm)=10; Dimension H (mm)=6; Dimension A (mm)=11.6; Dimension L (mm)=16; Dimension J (mm)=6; Dimension S (mm)=-; Dimension N (mm)=7; Dimension G (mm)=M3 x 0.5; Dimension Q (mm)=4.5}}
