CKD SCM Series Super Micro CylinderSCM-40B
#Grup produk P103129446
Spesifikasi
| Refueling | Unnecessary (Use turbine oil ISO VG32 when refueling) |
|---|---|
| Cushion | Air cushion |
| Operating Piston Speed (mm/s) | 30 to 1000 (Please use within the allowable energy absorption) |
| Effective Length (mm) | 8.6 (Air cushion) |
| Maximum Working Pressure (MPa) | 1 |
| Allowable Kinetic Energy (J) | 3.7 (with air cushion) |
| Ambient Temperature (°C) | -10 to 60 (but not freezing) |
| Connection aperture | Rc1/8 |
| Guaranteed Pressure Resistance (MPa) | 1.6 |
| Minimum Working Pressure (MPa) | 0.1 |
| Operation Method | Double acting |
| Stroke length tolerance | 0 to +1.4 (-1500) |
| Tube Inner Diameter (mm) | 40 |
| Working Fluid | Compressed air |
