Kitz Dougtail Iron Gate Valve
#Grup produk P103049991
Spesifikasi
| Material (stem) | SUS420J2 |
|---|---|
| Material (disk) | SCS1 |
| Material (bonnet) | FCD-S |
| Cap Material | FCD-S |
| Ball Material | SCS1 |
| Body Material | FCD-S |
| Compliance standard | JV4-2 equivalent |
| Connection Shape | Flange: JIS B2239 16K |
| Cover Material | FCD-S |
| Dimension H (mm) | 219 |
| Dimension L (mm) | 140 |
| Dimensions d (mm) | 90 |
| Material (Gasket) | C1100P-O |
| Material (Handle) | FCD450-10 |
| Material (Packing) | Non-asbestos |
| Maximum Permissible Pressure (MPa) | 2.2 (-10°C - 120°C electrostatic running water), 2 (-10°C - 220°C steam, air, gas, oil, pulsating water) |
| Nominal Diameter | 32A |
