Kitz 125-Type Bronze Gate Valve (Stem Non-Ascending Type, Screw-In Type)
#Grup produk P103049779
Spesifikasi
| Material (disk) | ASTM B62 |
|---|---|
| Material (Handle) | ADC12 |
| Dimension H (mm) | 280 |
| Dimensions d (mm) | 155 |
| Dimension L (mm) | 121 |
| Body Material | Bronze casting |
| Class | 125 type |
| Connection Method | The screw-shaped |
| Fluid Used | water vapor |
| Handle Shape | circular |
| Material (Packing) | Non-asbestos packing |
| Material (bonnet) | Bronze casting (ring/C3771BE) |
| Material (stem) | Dezincification brass rod |
| Maximum Working Pressure (MPa) | 1.18 (+120°C below the static water flow), 0.88 (saturated steam) |
| Nominal Diameter A | 100 |
| Nominal Diameter B | 4 |
| Shape | straight |
| Valve Type | Gate valve |
