Kitz General Purpose Wafer Chuck Valve Made of Cast Iron
#Grup produk P103049399
Spesifikasi
| Material (hinge pin) | SUS304 |
|---|---|
| Nominal Diameter | 250A |
| Dimension H (mm) | 290 |
| Dimension L (mm) | 109 |
| Dimensions d (mm) | 90 |
| Material (plug) | S45CH: 40A-125A |
| Accessories | Piping bolts and nuts |
| Ball Material | CAC406, C3531 (bypass valve) |
| Body Material | FC250+NBR |
| Cap Material | C3771BE: 40A-125A (bypass valve), CAC406: 150A-450A (bypass valve) |
| Compliance standard | Public building construction standard specification equivalent: 50A-450A |
| Connection Shape | Wafer: JIS 10K |
| Cover Material | C3771BE: 40A-125A (bypass valve), CAC406: 150A-450A (bypass valve) |
| Material (Handle) | ADC12: 40A, 150A-450A (bypass valve), ZDC2: 50A-125A (bypass valve) |
| Material (Lever Part) | ADC12: 40A, 150A-450A (bypass valve), ZDC2: 50A-125A (bypass valve) |
| Material (Packing) | Non-asbestos: bypass valve |
| Material (bonnet) | C3771BE: 40A-125A (bypass valve), CAC406: 150A-450A (bypass valve) |
| Material (disk) | CAC406, C3531 (bypass valve) |
| Material (stem) | C3531 (bypass valve) |
| Maximum Permissible Pressure (MPa) | 1.4 (80°C below the static water flow), 1 (80°C or less of oil, pulsating water, air) |
