SKF CCK/HA3C4W33 Type Spherical Roller Bearings 23036 CCK/HA3C4W33 with Tapered Bore and Relubrication Features 1pc

Name: SKF CCK/HA3C4W33 Type Spherical Roller Bearings 23036 CCK/HA3C4W33 with Tapered Bore and Relubrication Features 1pc
Brand: SKF
SKU: S047874091
Price: 57999900 IDR
Availability: OutOfStock

#Nomor SKU S047874091

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	23036 CCK/HA3C4W33
Unit	1pc
Bore Diameter (mm)	180
Outside Diameter (mm)	280
Width (mm)	74
Basic Dynamic Load Rating (kN)	883
Basic Static Load Rating (kN)	1250
Limiting Speed (r/minute)	2600
Number of Rows	2
Locating Feature, Bearing Outer Ring	Without
Bore Type	Tapered 1:12
Cage	Sheet metal
Radial Internal Clearance	C4
Tolerance Class for Dimensions	Normal
Tolerance Class for Run-out	P5
Sealing	Without
Lubricant	None
Relubrication Feature	With
Candidate for Remanufacturing	Yes
UNSPSC	31171510
Reference Speed (r/minute)	2000
Berat (Kg)	15.9
Tanggal Produk Terdaftar	13 August 2025
Terakhir Diperbaharui	14 August 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.

Peringatan

- Foto pada halaman ini hanya sebagai referensi (ilustrasi) yang sesuai dengan fungsinya
- Produk yang diterima akan sesuai dengan informasi model number/part number/size/warna/type/atribut yang tertera pada website

Feature

Accommodate misalignment; High load carrying capacity; Relubrication features; Low friction and long service life; Increased wear resistance
