MACURCO Fixed Gas Detection GBC2120 CM-6 (36CF92)/GD-6 (36CF89) Carbon Monoxide/Natural /Propane 4X Transmitter Controller 2 Relay Ip66 1unit
Rp23.999.900
Persediaan
Spesifikasi Produk
| Model Number | GBC2120 |
|---|---|
| Unit | 1unit |
| UNSPSC | 46171613 |
| Standards | ISO 9001:2015 |
| Includes Mounting Hardware | Yes |
| Product Type | Controller for Transmitter |
| Includes | Mounting Hardware |
| Maximum Operating Temperature (°F) | 125 |
| For use with | CM-6 (36CF92)GD-6 (36CF89) |
| Minimum Operating Temperature (°F) | 32 |
| Features | Shut Down Up to 8 Boilers Individually Via Expansion Relays |
| Overall Height (inch) | 9.8 |
| Overall Width (inch) | 8 |
| Power Source | Wire Leads |
| Housing Material | Polycarbonate |
| IP Rating | IP66 |
| Mounting Location | Wall |
| Overall Depth (inch) | 4.5 |
| Mount Type | Screws |
| Alert Type | Internal Buzzer; Light |
| Detection Product Type | Control Panel |
| Display Type | Digital |
| Visual Alert Type | Green LED; Red LED |
| Gas Detected | Carbon Monoxide; Natural Gas; Propane |
| Display Screen Type | LED |
| For Environment | Buildings; Homes |
| Output Type | SPDT Relays |
| Alarm Volume Level (dBA) | 90 @1ft |
| Maximum Operating Humidity (%) | 95 |
| Minimum Operating Humidity (%) | 0 (zero) |
| Operating Frequency (Hz) | 60 |
| Status indicator | LED |
| Ties Into | Building Automation Panels; HVAC Systems; Security Systems |
| Coverage Area (ft²) | 1257 |
| Data logger | No |
| NEMA Enclosure Rating | 4X |
| Number of Relays | 2 |
| Market | Commercial; Industrial; Residential |
| Output Current (mA) | 350 |
| Output voltage (V) | 120/240 AC |
| Detectors Per Channel | 4 |
| For Number of Detectors | 4 |
| Input Channels | 2 |
| Communication Protocol | Relays |
| For Number of Zones | 2 |
| Mobility | Mounting |
| Berat (Kg) | 1.3 |
| Tanggal Produk Terdaftar | 31 July 2024 |
| Terakhir Diperbaharui | 07 October 2025 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Fixed gas detector control panels interface with ventilation, suppression, and alert systems to initiate an action when a gas has been detected at specified concentrations.
