OTC DAIHEN Welding Power Supply Water Cooled AEP-500 1set

Name: OTC DAIHEN Welding Power Supply Water Cooled AEP-500 1set
Brand: OTC DAIHEN
SKU: S034591604
Price: 179999900 IDR
Availability: InStock

#Nomor SKU S034591604

OTC DAIHEN

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	AEP-500
Unit	1set
Phases	Single Phase
Rated Frequency (Hz)	50/60
Rated Input Power (KVA)	47.0 (27.9kW)
Rated Input Power (kW)	27.9
Rated Output Current (A)	500
Rated Output Voltage (V)	30 (40V at Stick welding)
Max. Open Circuit Voltage (V)	79
Rated Duty Cycle (%)	60
Slope Time (s)	Down : 0.1-5; Up : 0.1-5
Gas Flow Time (s)	Pre : 3-50; After : 3-20
Crater Fill Control	ON/OFF/Repeat change over system
Dimensions (WxDxH) (mm)	508x724x895
Cable Hose	BMRH-5001
Current Range (A)	Crater fill/initial : 5-500; Pulse/Base : 5-500
Rated Welding Current (A)	DC : 500; AC : 400
Cooling Method	Water-cooled
Electrode (Ømm)	1.0, 1.6, 2.4, 3.2, 4.0, 4.8, 6.4
Cable Length (m)	4
Rated Utilization Rate (%)	100
Berat (Kg)	273.0
Tanggal Produk Terdaftar	07 November 2022
Terakhir Diperbaharui	27 May 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

Thyrister Control AC/DC Pulsed TIG Welding Machine ACCUTIG 300P/ 500P
Highest-quality AC/DC Pulsed TIG welding machine achieve high quality welding of aluminum by varied AC TIG current waveforms and pulse functions.
7 welding modes :
- DC PULSED TIC
- DC Stick
- Rectangular Wave AC Pulsed TIG
- Rectangular Wave AC Stick
- DC TIG
- TIG Arc Spot
- Rectangular Wave AC TIG
