A board hole insertion terminal type contact with a wide range of pole specifications is gold-plated, and a high-reliability self-cleaning mechanism with a twin contact ensures high reliability.
A lineup of types with washable sealing tape.
OMRON Dip Switch A6T A6T-4102 1pc
Rp28.000
Persediaan
Spesifikasi Produk
| Model Number | A6T-4102 |
|---|---|
| Unit | 1pc |
| Contact Resistance (miliΩ) | 200 or less (initial value) |
| Electrical Rating | 24V DC 25mA, 3.5V DC 10μA (minimum current) |
| Type | Flat type (with seal tape) |
| Dimension A (mm) | 11.1 |
| Shock Resistance Malfunction (m/s²) | 300 or more |
| Operating Humidity Range (%RH) | 35 to 95 (at +5 to + 35°C) |
| Vibration Resistance (Malfunction) | 10-55Hz double amplitude 1.5mm |
| Operating Temperature Range (°С) | -20 to +70 60% RH or less (with no icing or condensation) |
| Operating Force (N) | 0.29 to 9.8 |
| Electrical Durability (times) | 1000 or more |
| Withstand Voltage | Between terminals: AC500V 1min |
| Insulation Resistance (MΩ) | 100 or more (at 250 VDC) |
| Number of Poles | 4 |
| AS ONE Part Number | 64-3337-23 |
| M Code | 39027186 |
| Berat (Kg) | 0.3 |
| Tanggal Produk Terdaftar | 27 June 2022 |
| Terakhir Diperbaharui | 15 August 2025 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Substrate hole insertion terminal type with rich number specifications The contact part is gold-plated, and high reliability is secured with a self-clean mechanism by sliding with a twin contact.
Assorted the type with cleaning tape that can be cleaned.
