TOA Digital Mixer Amplifier ZA-3248DMZ-AS with Mp3, Zones 480W 1unit
Rp8.099.900
Persediaan
Spesifikasi Produk
| Model Number | ZA-3248DMZ-AS |
|---|---|
| Unit | 1unit |
| Total Harmonic Distortion | Under 1% at 1 kHz, 1/3 rated power |
| Ventilation | Fan Cooling |
| Accessories | Removable terminal plug (2 pins) x 5 |
| Muting | MIC 1: Mutes other input signals by 0-30 dB attenuation |
| Phantom Power | DC +21 V (MIC 1) |
| Tone Control | Bass: ±10 dB at 100 Hz; Treble: ±10 dB at 10 kHz |
| Frequency Response (Hz) | 50-20000 |
| Dimensions (WxHxD) (mm) | 420x100.9x357 |
| Power Source | 100 - 240 V AC, 50/60Hz or 24 V DC |
| Power Consumption (W) | 99 (AC operation at 1/8 maximum outputithout clip) |
| Output Rating (W) | 480 |
| Finish | Panel: ABS resin, black; Case: Steel plate, black |
| SN Ratio (dB) | Over 60 |
| Indicator | Power, Signal, Peak, Protect |
| Berat (Kg) | 5.4 |
| Tanggal Produk Terdaftar | 27 April 2022 |
| Terakhir Diperbaharui | 27 May 2025 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
ZA-3248DMZ-AS 1 is a high performance yet cost-effective mixer power amplifier equipped with MP3,Bluetooth function and Zone selection. Ideal for broadcasting, paging, or background music in schools, offices, shops, houses of worship and large ballrooms.
Feature
Input :MIC 1: 1 mV (-60 dB), 600 Ω, balanced, phone jack, selectable to RJ45;
MIC 2-3: 1 mV (-60 dB), 600 Ω, balanced, phone jack;
MIC 4: 1 mV (-60 dB) 600 Ω, balanced, phone jack, selectable to AUX 1;
AUX 1: 100 mV (-20 dB), 10 kΩ, unbalanced, RCA pin jack, selectable to MIC 4;
AUX 2: 100 mV (-20 dB), 10 kΩ, unbalanced, RCA pin jack;
MP3: LED Display, Support USB, SD/MMC card (up to 32GB), Bluetooth, Radio FM, Record
Output :
Speaker out: Speaker Output in screw type terminal
Direct line (selectable): 21 Ω (100 V) or 4 Ω
Rec out: 0 dB, 600 Ω, unbalanced, RCA pin jack
5-zone selector (all zones simultaneously selectable)
