OMRON Small Pushbutton Switch (Round) (Small Square Body) A3A A3AT-90L1-00R 1pc

Name: OMRON Small Pushbutton Switch (Round) (Small Square Body) A3A A3AT-90L1-00R 1pc
Brand: OMRON
SKU: S029729593
Price: 83000 IDR
Availability: InStock

#Nomor SKU S029729593

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	A3AT-90L1-00R
Unit	1pc
Allowable Operation Frequency	Mechanical: Up to 60 times / min, Electrical: 20 times / min
Electrical Durability	50,000 times or more
Protection Class	IP40
Operating Ambient Temperature (°C)	-10 to +55 (with no icing or condensation)
Contact Resistance (miliΩ)	100 or less (initial value)
Withstand Voltage	Between homopolar terminals: AC600V 50 / 60Hz 1min / Between each terminal and ground: AC2000V 50 / 60Hz 1min
Storage Temperature (°C)	-25 to +65 (with no icing or condensation)
Button Color	Red
Type of Operation	Alternate
Contact Configuration	1a
Mechanical Durability	50,000 times or more (once set or reset)
Terminal Shape	Solder terminal
Button Shape	Round
Ambient Relative Humidity (RH)	35 to 85
Insulation Resistance (MΩ)	100 or more (with DC500V mega)
Type	Non-illuminated Type
Impact Resistance Durability (m/s²)	500
Vibration Resistance (Malfunction)	10 to 55Hz, double amplitude 1.5mm (malfunction 1ms)
M Code	39011131
Berat (Kg)	0.2
Tanggal Produk Terdaftar	23 November 2021
Terakhir Diperbaharui	15 August 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

High-capacity, compact pushbutton switch Can be used as a power switch that requires high-capacity cutoff.
Open and close from minute loads (minimum applicable load DC5V 1mA) to high capacity loads.

Feature

High capacity, compact push button switch
Available as a power supply that requires high capacity.
Open and closes to high capacity load from micro-load (minimum application load DC5V 1 MA) .
