Federal Kabel Kabel Listrik Fleksibel NYAF 450/750V 1x35mm² Pink 1roll(100m)

Name: Federal Kabel Kabel Listrik Fleksibel NYAF 450/750V 1x35mm² Pink 1roll(100m)
Brand: Federal Kabel
SKU: S028580034
Price: 9899900 IDR
Availability: OutOfStock

#Nomor SKU S028580034

Wishlist

0 Ulasan

Spesifikasi Produk

Unit	1roll(100m)
Color	Pink
Number of Cores	1
Nominal Cross Section Area (mm²)	35
Current Carrying Capacity (A)	156 (at 30°C)
Maximum Operating Temperature (°C)	70
Conductor Diameter (N x mm)	7 x 40/0.40
Thickness (mm)	1.36
Overall Diameter (mm)	11.2
DC Resistance for Conductor (ohm/km)	Max 0.55 (at 20°C)
DC Resistance for Insulation (MΩ.km)	Min 20 (at 20°C)
Short Circuit Current (kA)	4.03 (per 1sec)
Standard	IEC 60227-6
Conductor Material	Annealed Bunched Copper Wire
Insulation Material	PVC
Core x Size (mm²)	1x35
Length (m)	100
Berat (Kg)	40.0
Tanggal Produk Terdaftar	28 September 2021
Terakhir Diperbaharui	27 May 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

Single core insulated conductor, without sheath, for general purposes. Suitable for fixed protected installation, or on, lighting or control gear for rated voltages up to 450/750 V. Installation in surface mounted or embedded conduits, or similar closed systems.Single core insulated conductor, without sheath, for general purposes. Suitable for fixed protected installation, or on, lighting or control gear for rated voltages up to 450/750 V. Installation in surface mounted or embedded conduits, or similar closed systems.
