CKD Direct Acting 3 Port Valve Universal Type AG AG31-02-1-02G-AC100V 1unit

Name: CKD Direct Acting 3 Port Valve Universal Type AG AG31-02-1-02G-AC100V 1unit
Brand: CKD
SKU: S010561607
Price: 1299900 IDR
Availability: OutOfStock

#Nomor SKU S010561607

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	AG31-02-1-02G-AC100V
Unit	1unit
Orifice Diameter (phi mm)	TOP: 1.5, BODEY: 1.5
Valve Structure	Direct acting poppet structure
Coil Housing	2G
Maximum Working Pressure (MPa)	1
Connection aperture	Rc1/4
Withstand Pressure (MPa)	25 (at water pressure)
Atmosphere	No corrosive gas or explosive gas
Mounting attitude	freely
Ambient Temperature (°C)	-20 to 60
Mass (kg)	0.36
Rated Voltage	AC 100 V (AC 100 V 50/60 Hz, AC 110 V 60 Hz can be used)
Valve Seat Leakage (cm³/minute)	0.2 or less (ANR) (in the air)
Heat resistant class	B
Maximum Operating Pressure Differential (MPa)	[Air] 0.7, [Water, Kerosene] 0.7
Apparent power (VA)	[Holding] 50 Hz: 14, 60 Hz: 11, [Starting] 50 Hz: 20, 60 Hz: 16
Working Fluid	Air, low vacuum [1.33 x 10 2 Pa (abs)], water, kerosene
Fluid Temperature (°C)	-10 to 60 (no freezing)
Flow Characteristics	C [dm <sup> 3/(s, bar)]: (TOP) 0.29 (BODY) 0.29, b: (TOP) 0.64 (BODY) 0.53, Cv value: (TOP) 0.09 (BODY) 0.09
Power Consumption (W)	50 Hz: 6, 60 Hz: 4.2
Material (Body Seal)	Body: Brass, Seal: Nitrile rubber
M Code	40127482
Berat (Kg)	0.8
Tanggal Produk Terdaftar	14 May 2019
Terakhir Diperbaharui	27 May 2025
