OMRON PLC CP1L series Programmable Controller CP1L-L20DT-D 1pc

Name: OMRON PLC CP1L series Programmable Controller CP1L-L20DT-D 1pc
Brand: OMRON
SKU: S005208917
Price: 7099900 IDR
Availability: InStock

#Nomor SKU S005208917

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	CP1L-L20DT-D
Unit	1pc
Type	USB port type
Applicable Standard	cULus (Class I Div2 Hazardous Location Certified Product), NK, Lloyd, EC Directive
Power Supply	DC power supply
Type of control	Stored program method
Memory	Trace memory / 4000 words
Data Memory	10K words D0 to D9999, D32000 to D32767
Suitable CPU	Memory capacity/5K step high-speed counter/100kHz 4-axis pulse output/100kHz 2-axis
Communication Function	Built-in peripheral port (USB1.1) x 1: Support software connection only. Up to 1 serial communication option board can be installed. Up to 1 Ethernet communication option board can be installed.
Number of Input/Output Points	12 inputs, 8 outputs
Command	Word length: 1 to 7 steps/1 instruction Types: Approx. 500 types (FUN No. is 3 digits)
Clock Function	Yes Accuracy/monthly difference -4.5 minutes to -0.5 minutes (ambient temperature 55°C), -2.0 minutes to +2.0 minutes (ambient temperature 25°C), -2.5 minutes to +1.5 minutes (ambient temperature 0°C)
Timer / counter	4096 points (T0 to T4095) / 4096 points (C0 to C4095)
Memory Backup	Flash memory/user programs, parameters (PC system settings, etc.), comment information, all data memory areas can be saved in flash memory (data memory initial values) Battery backup/retention relays, data memory, counters (flags and current values)
Register points	Data register/16 points (16 bits) DR0 to DR15 Index register/16 points (32 bits) IR0 to IR15
Function	Maximum number of function block definitions: 128, maximum number of instances: 256 Languages that can be used in function block definitions: ladder chart, structured text (ST)
Number of tasks	288 (cycle execution task 32, interrupt task 256)
Programming language	Ladder chart method
In / Out control method	Combined use of cyclic scan and processing method
M Code	39032892
Berat (Kg)	0.2
Tanggal Produk Terdaftar	04 September 2018
Terakhir Diperbaharui	27 May 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Feature

Pulse Output
Pulse output: Trapezoidal/S-curve acceleration/deceleration (duty ratio fixed at 50%), 2 points, 1 Hz to 100 kHz (CCW/CW or pulse + direction) PWM output: Duty ratio 0.0 to 100.0% variable (0.1% unit or 1% unit specified), 2 points 0.1 to 6553.5 Hz or 1 to 32800 Hz (accuracy +1%/-0%: 0.1 to 10000 Hz, +5%/-0%: 10000 to 32800 Hz)
relay
Input: 1600 points (0 to 99CH), Output: 1600 points (100 to 199CH), 1: 1 link area: 256 points (16CH), Serial PLC link: 1440 points (90CH), Cross subsidization: 8192 points (512CH) , Temporary storage: 16 points (TR0 to TR15), Retention: 8192 points (512CH), Special assistance: (Read-only / non-writeable) 7168 points (448CH), (Read / write possible) 8192 points (512CH)
