Mitutoyo 543 Series ABS Digimatic Indicator ID-CX
#Grup produk P103933496
Spesifikasi
| Contact Point (mm) | Spherical R = 1.5 (Carbide) |
|---|---|
| Return Error (mm) | 0.02 or less |
| Quantization Error | Not including +/- 1 count |
| Accessories | Button-type silver oxide battery SR44 for monitor (1 piece) |
| Repeat Precision (mm) | 0.01 or less |
| Minimum display amount (mm) | 0.01 |
| Wide Range Accuracy (mm) | 0.02 or less |
| Measuring Force (N) | 0.9 or less |
| Back lid specification | Center-lug back |
| Battery Life (continuous time) | 7000 |
| Display | 6 digit LCD, sign |
| Minimum Range (mm) | 0.01 |
| Mitutoyo Part Number | 543-400 |
| Operating Temperature Range (°C) | 0-40 |
| Outer Frame Diameter (mm) | 59 |
| Power Supply | SR44 (button type, silver oxide battery) x 1 |
| Series | 543 |
| Storage Temperature Range (°C) | 0-60 |
| Weight (g) | 170 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Function : Zero set (INC length measurement system), Preset (ABS length measurement system origin setting), Direction switching, Tolerance judgment, 330 degrees display rotation function, Display value hold (when no externally connected device is installed), Calculation f (x) = Ax, data output (when external connection device is installed), function lock, low battery alarm, error alarm
Warning
- For separately delivered items, if ordered by cash on delivery, it will be shipped after the next day [For products with calibration documents, it will not be possible to cancel after ordering] - For products with calibration documents and traceability system diagram, order on the web Only. - Documents that include (JCSS Calibration Certificate), (General Calibration Certificate / Traceability System Diagram) and (Calibration Certificate / Traceability System Diagram) are included in the product number. - For products with calibration documents, " Mitutoyo Calibration Certificate with Traceability System Diagram '', which the manufacturer performs calibration, and " Calibration Company Implementation Calibration Certificate, '' which performs calibration at calibration points based on the calibration company based on the ISO 9001 quality management system With traceability system diagram ".Feature
- In the ABS (absolute) method, which has an absolute origin on the scale, the set origin is retained as a measurement reference point even after the power is turned off, so that troublesome home position adjustment is not required when the power is turned on again, and measurement can be performed at the same time when the power is turned on. You can start. - The adoption of the ABS method has eliminated overspeed errors. - By setting the upper and lower limits, tolerance judgment measurement can be performed. In addition, only the tolerance judgment result can be enlarged and displayed. - 7000 hours of continuous battery life with a single battery. - There is an output terminal for measurement data, and a statistical process control system or measurement system can be configured.Ulasan Produk
