Unitized stepping control function suitable for pump control and process control.
. There are 6 types of steps, 2 types of 12 circuits.
. It is possible to open and close 2A (AC 250 V, DC 30 V) by relay contact output.
. Reset input returns to step initial state.
. With power failure holding function to memorize step state in internal memory for 10 days even at power failure. (The output contact during power failure is OFF.)
. Built-in fault detection function to detect ON fault of built-in relay drive element due to external noise etc. Alarm LED is displayed, alarm output at reed point. (Contact failure of relay contacts, welding can not be detected.)
. The terminal block is a finger protect structure that prevents electric shock.
. LED display with step status at a glance.
OMRON Stepping, relay unit G 9 B
#Grup produk P102366332
Spesifikasi
| Tensile Strength (N) | (Terminal) 49 |
|---|---|
| Noise resistance | Noise level 1.5kV Pulse width 50ns / 1μs |
| Allowable Voltage Range (V) | 85 to 110% of rated voltage |
| Ambient Relative Humidity (RH) | 35 to 85 |
| Rated Voltage (V) | AC200 |
| Coil Rated Voltage (V) | AC200 |
| Vibration Resistance (Durability) | 10 to 55 to 10 Hz, single amplitude 0.375 mm (double amplitude 0.75 mm) |
| Contact Resistance (miliΩ) | 100 or less (DC5V 100mA voltage drop method) |
| Current Consumption (mA) | 120 or less |
| Electrical Durability | 300,000 steps or more (rated load, switching frequency 3600 steps / h) (ambient temperature / + 23 ° C) |
| Impact Resistance Durability (m/s²) | 500 |
| Insulation Resistance (MΩ) | 100 or more (at 500 VDC megger) (between control circuit and output contact/alarm contact) 100 or more (at 500 VDC megger) (between output contact and alarm contact) |
| Maximum Contact Voltage (V) | AC250, DC30 |
| Mechanical Durability | 10 million steps or more (no contact, 3600 steps / h switching frequency) |
| Operating Ambient Temperature (°C) | -25 to +55 (with no icing or condensation) |
| Shock Resistance Malfunction (m/s²) | 200 |
| Type | General relay |
| Vibration Resistance (Malfunction) | 10 to 55 to 10 Hz, single amplitude 0.375 mm (double amplitude 0.75 mm) |
