OMRON Programmable controller CS series DeviceNet remote I/O master station unit
#Grup produk P102365999
Spesifikasi
| Protocol | Communication / DeviceNet compliant |
|---|---|
| Noise resistance | Compliant with IEC61000-4-4 2kV (power line) |
| Current Consumption (mA) | Communication power supply / 30 or less, internal circuit power supply / 290 or less |
| Applicable Standard | cULus (Class I Div2 Hazardous Location Certified Product), NK, Lloyd, EC Directive |
| Power Supply | 24 VDC supplied from communication / external |
| Atmosphere | No corrosive gas |
| Unit Type | CS1 CPU high-function unit |
| Ambient Relative Humidity (RH) | 10 to 90 (no condensation) |
| Cable | Communication / DeviceNet dedicated cable |
| Communication Function | Remote I / O communication master (fixed or free assignment), remote I / O communication slave (fixed or free assignment), message communication |
| Communication Method | 5 dedicated cables (2 signal systems, 2 power systems, 1 shield), 4 dedicated flat cables (2 signal cables, 2 power cables) |
| Communication Speed (bit/s) | 500k / 250k / 125k |
| Control | Combination of multi-drop method and T-branch method is possible |
| Current Consumption (A) | 0.29 (5V system) |
| Maximum number of connections | Slave / (Remote I / O, Explicit message service) 63 units |
| Operating Ambient Temperature (°C) | 0 to 55 |
| Power Supply Voltage (V) | DC11 to 25 |
| Storage Temperature (°C) | -20 to +75 (excluding battery) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Up to 32000 points (2000 CH) / Master can be controlled. .Besides being a master of the remote I / O communication function, it can also be used as a slave of the remote I / O communication function. . Master and slave functions can be used at the same time. . In the message communication function or remote programming / monitoring from the CX - Programmer, it is possible to handle the DeviceNet network as a seamless network similar to other Controller Link Ethernet etc.
